57NR
Gram Lights 57NR: the newest wheel in the R series
The 57NR is the newest wheel in Gram Lights' R series, the line that includes the 57CR, 57DR and 57XR. RAYS calls it the toughest of the R series: ten spokes in RAYS' classic layout, cast in one piece in Japan and built to spread the load when a car is getting thrown sideways. This page has every 57NR and 57NR Limited we carry, from 17 to 19 inches in 5x114.3, 5x100, 5x112 and 5x120.
Design and construction
Ten spokes spread stress evenly around the wheel, and the face depth changes with width: Face-1 on the narrow sizes, up to Face-3 on the widest 19x10.5. RAYS knurls the bead seat, a fine texture that helps keep the tire from slipping on the rim under hard launches and braking. It's a one-piece cast wheel, certified to RAYS' JWL+R Spec 1 strength standard.
The regular 57NR comes in Glass Black and Dark Bronze (RAYS color code JPJ). The 57NR Limited is the same wheel in RAYS Black Metal Coat, a dark chrome finish, and it comes with the luminous yellow spoke sticker that's a favorite in the drift scene.
57NR sizes, offsets and bolt patterns
Every size we list on this page right now, with the offsets, bolt patterns and finishes it comes in. Use the filters on the product grid to narrow it down.
| Size | Offsets | Bolt patterns | Finishes |
|---|---|---|---|
| 17x7 | +38, +47 | 4x100, 5x114.3 | RAYS Black Metal Coat |
| 18x7.5 | +38, +42, +45 | 5x100, 5x112, 5x114.3 | RAYS Black Metal Coat |
| 18x8.5 | +22, +36, +38, +45 | 5x100, 5x112, 5x114.3, 5x120 | Dark Bronze, Glass Black, RAYS Black Metal Coat |
| 18x9.5 | +12, +22, +32, +36, +38, +45 | 5x100, 5x112, 5x114.3, 5x120 | Ceramic Pearl, Dark Bronze, Eternal Blue Pearl, Glass Black, Grace Silver, RAYS Black Metal Coat |
| 19x8 | +38, +45, +48 | 5x112, 5x114.3, 5x120 | Dark Bronze, RAYS Black Metal Coat |
| 19x8.5 | +22, +25, +34, +38, +44, +45 | 5x100, 5x108, 5x112, 5x114.3 | Dark Bronze, Glass Black, RAYS Black Metal Coat |
| 19x9.5 | +22, +25, +38, +45 | 5x100, 5x112, 5x114.3, 5x120 | Dark Bronze, Glass Black, RAYS Black Metal Coat |
| 19x10.5 | +12, +22 | 5x114.3 | Dark Bronze, Glass Black |
Shopping by size? See every Gram Lights wheel in 17 inch, 18 inch, 19 inch.
What cars does the 57NR fit?
Bolt pattern comes first: if it doesn't match your hub, nothing else matters. Then width and offset decide whether the wheel sits tucked, flush or out past the fender. Here's what we list in the patterns these cars use.
| Bolt pattern | Popular cars | 57NR sizes we list |
|---|---|---|
| 5x100 | Toyota GR86 / 86, Subaru BRZ, Scion FR-S; Subaru WRX and Impreza (2002-2014, non-STI) | 18x7.5, 18x8.5, 18x9.5, 19x8.5, 19x9.5 |
| 5x114.3 | Subaru WRX (2015+), WRX STI (2005-2021); Nissan 350Z / 370Z; Honda S2000; Mitsubishi Lancer Evolution VIII-X; Honda Civic and Civic Si (2006+); Mazda RX-7 (FD), Nissan 240SX (S14); Infiniti G35 / G37 / Q50, Lexus IS; Acura RSX, TSX, Integra (2023+); Ford Mustang (2015+), Tesla Model 3 / Y | 17x7, 18x7.5, 18x8.5, 18x9.5, 19x8, 19x8.5, 19x9.5, 19x10.5 |
| 5x120 | Honda Civic Type R (FK8, FL5); BMW 3 Series (E36, E46, E90, F30) | 18x8.5, 18x9.5, 19x8, 19x9.5 |
| 5x112 | Toyota GR Supra (A90); VW Golf GTI / Golf R, Audi A4 / S4 | 18x7.5, 18x8.5, 18x9.5, 19x8, 19x8.5, 19x9.5 |
| 4x100 | Mazda Miata (NA, NB, ND); Honda Civic (1992-2000), Acura Integra (1994-2001) | 17x7 |
| 5x108 | Ford Focus ST / RS | 19x8.5 |
Lower offsets push the wheel out; higher offsets tuck it in. Wide, low-offset sizes usually need fender rolling and some camber on a lowered car. Not sure? Call or text 813-535-5801 with your car, ride height and tire size and we'll pick the size with you.
57NR questions
What's the difference between the 57NR and the 57NR Limited?
The finish and the sticker. The 57NR Limited is the same ten-spoke wheel in RAYS Black Metal Coat with a luminous yellow sticker; the regular 57NR comes in Glass Black and Dark Bronze. Sizes overlap, and the table shows both.
Is the 57NR forged?
No. The 57NR is cast in one piece by RAYS in Japan, like every Gram Lights wheel.
57NR, 57CR or 57DR?
Ten spokes versus five or six. The 57NR has a busier, more modern face, and it comes in a wide spread of offsets in each size. The 57CR and 57DR come in more finishes and a few more small sizes, like 15x8.
Will the 57NR fit a GR86 or an FL5 Civic Type R?
The bolt patterns are there: we list the 57NR in 5x100 for the GR86, BRZ and FR-S, and in 5x120 for the FK8 and FL5 Type R. The car table on this page shows each size we list in your pattern. Call or text 813-535-5801 and we'll confirm the offset for your setup.
How much does a 57NR weigh?
RAYS doesn't publish 57NR weights on its spec sheets, so we don't list guessed numbers.
More Gram Lights
Questions on fitment or sizing? Call or text 813-535-5801. See the whole range on the Gram Lights page.
