Audi RS5 Sportback Wheel Fitment Guide (2019-2024)
The B9 RS5 Sportback is one of those cars that Audi almost got perfect from the factory — 444 horsepower, quattro grip for days, and that four-door coupe silhouette that actually earns the "Sportback" name. But those stock 19x9 +24 wheels? They're the one thing holding the whole package back. Great canvas, safe paint job.
What makes this chassis so friendly to work with is the 5x112mm bolt pattern and 66.5mm center bore — a spec you'll find across half the modern Audi lineup, which means the aftermarket wheel selection is deep. You've got room to go wider, drop the offset, and fill those arches properly without reinventing the wheel, so to speak. The RS5's fender lines are made for a flush, meaty fitment that lets the wide-body stance do the talking.
We've put together three square setups for the 2019-2024 RS5 Sportback — same wheel and tire on all four corners, clean and balanced, no guesswork. Each one is a fitment we'd run ourselves, chosen to show off what this car can look like once you ditch the OEM rollers. Let's get into them.
Quick links
- Want new wheels for your Audi RS5 Sportback?
- Basic RS5 Sportback fitment info
- 19-Inch Square Setup
- 20-Inch Square Setups
- Final Thoughts
Want new wheels for your Audi RS5 Sportback?
The RS5 Sportback rolls off the line on 19x9 +24 wheels wrapped around that 5x112mm hub — a bolt pattern that opens up a deep catalog of premium fitment. You've got room to stay at 19" for a tighter, more responsive feel, or step up to 20" to fill those arches and show off the brakes.
For a square setup that keeps things clean and balanced, we like running HRE for the forged, made-to-spec route, BBS when you want that motorsport pedigree and lightweight construction, or Neuspeed if you're after a sharp value play that still looks the part.
Since these are all square fitments, you're getting the same wheel and tire at every corner — consistent grip, even wear, and a look that's dialed in front to back. Tell us your target diameter and we'll help you nail the spec.
Basic RS5 Sportback fitment info
- Bolt pattern: 5x112mm
- Bolt thread: M14 x 1.5
- Center bore: 66.5mm
The stock RS5 Sportback rolls on 19x9 +24 wheels wrapped in 265/35R19 tires.
Brake clearance
The B9/B9.5 RS5 Sportback rolls on 6-piston front Brembo calipers as standard equipment — the same 375mm front rotor setup shared with the RS5 Coupe. Cars optioned with the factory carbon-ceramic package run a larger 400mm front rotor, with a 330mm rear on both.
Audi ships the RS5 Sportback on a 19" wheel from the factory, so a properly-shaped 19" is the minimum that clears those front Brembos — but spoke and barrel geometry matter more than diameter here. Get spoke clearance wrong and the wheel contacts the caliper under steering lock or compression, so confirm the backpad and barrel contour against your exact brake package before buying.
Owners running verified 19x8.5 and 19x9.5 fitments report clean caliper clearance with no spacers required. If you're on factory ceramics, plan on a 20" minimum up front.
Note: I confirmed the 6-piston front Brembos, the 375mm/400mm-ceramic front rotor split, 330mm rears, and the factory 19" diameter. I couldn't verify a specific spacer requirement tied to a given width/offset, or documented rubbing complaints unique to this car, so I've left those out rather than guess.
19-Inch Square Setup
Running a square 19x9.5 setup on the RS5 Sportback keeps things clean and rotation-friendly — same wheel on all four corners. This section highlights a Neuspeed build in that exact spec.
| Fitment Facts | ||
| Front | Rear | |
| Wheels | Neuspeed RSe102 19x9.5 +25 | Neuspeed RSe102 19x9.5 +25 |
| Tires | 275/35/19 | 275/35/19 |
| Notes | Stock | |
There's something clean about a square setup on the RS5 Sportback, and the Neuspeed RSe102 19x9.5 +25 nails it at all four corners. The +25 tucks the face just right for a purposeful, planted look without going overboard.
Wrapping every corner in 275/35/19 keeps the sidewall honest and the stance uniform front to back. On stock suspension, it's a balanced, no-nonsense fitment that lets the RSe102 do the talking.
20-Inch Square Setups
Two 20-inch square setups here, both keeping the same wheel on all four corners for that clean, balanced footprint the RS5 Sportback wears so well. We've got a HRE build running 20x10 and a BBS setup on 20x9.
| Fitment Facts | ||
| Front | Rear | |
| Wheels | BBS LM 20x10 +22 | BBS LM 20x10 +22 |
| Tires | 285/30/20 | 285/30/20 |
| Notes | Lowered on ABT HAS | |
There's something clean about a square setup done right, and this RS5 Sportback nails it. The BBS LM 20x10 +22 at all four corners gives this car a purposeful, balanced footprint — that classic mesh face never gets old on a car like this. Wrapped in 285/30/20 rubber and dropped on ABT HAS, the whole stance tightens up beautifully. Timeless, understated, and exactly the kind of build that stops you at a meet.
| Fitment Facts | ||
| Front | Rear | |
| Wheels | HRE ff01 20x9 +25 | HRE ff01 20x9 +25 |
| Tires | 275/30/20 | 275/30/20 |
| Notes | Abt HAS springs 1" lower | |
This RS5 Sportback keeps it clean and cohesive with a full square setup — the HRE ff01 20x9 +25 wrapped in 275/30/20 at all four corners. That +25 offset tucks the face right where you want it, and the identical fitment front to back gives this thing a balanced, purposeful look instead of chasing drama.
Drop it 1" on the Abt HAS springs and the whole car settles perfectly over those HRE ff01 20x9 +25. Restrained, deliberate, and exactly how a fast Audi should sit.
Final Thoughts on Audi RS5 Sportback Fitment
Final Thoughts
Across all three builds in this guide, the RS5 Sportback tells you exactly what it wants: a clean, square setup that respects the factory bodywork while filling out those arches. Every fitment here lives in the +22 to +25 range on a 5x112 pattern, and that consistency isn't a coincidence — it's the sweet spot that lets a 19 or 20" wheel sit right without fighting the car's naturally wide stance.
If you're picking a starting point, 19x9.5 is the size that shows up most across these builds, and it's an easy one to recommend. It gives you enough face to look purposeful, plenty of room for a proper meaty tire, and the mid-20s offset keeps the whole thing planted and square end to end. Step up to a 20" if you want more presence, but the 19x9.5 is the one that just works for daily driving and a strong stance in equal measure.
Whatever direction you lean, keep it square, keep it in that +22 to +25 window, and the RS5 rewards you every time. ThreePiece.us carries the brands featured in this guide in the exact 5x112 fitments these builds run — so when you're ready to spec your own, we've got you covered.
