Oracle 16-23 Toyota Tacoma Lensless LED Headlights - 8700-TAC

The ORACLE Lighting Lensless LED Headlights (8700-TAC) are a genuine leap forward in headlight technology purpose-built for the 2016–2023 Toyota Tacoma Gen 3. Rather than evolving the century-old concept of protecting a light source behind a large outer polycarbonate lens, ORACLE eliminated that lens entirely — building a new lighting platform from the ground up around sealed, modular LED emitter pods. The result is a headlight assembly that addresses every common failure point of traditional headlights while delivering a striking, aggressive appearance that sets your Tacoma apart on the trail or the street.

Key Features & Benefits

• Multiple-patent-pending Lensless Architecture: The outer polycarbonate lens — the component responsible for fogging, yellowing, oxidation, cracking, and condensation — is completely eliminated. No lens means no lens failures, period.
• 1" Thick Ballistics-Grade PMMA Optics: The emitter optic covers roughly 96% less surface area than a traditional headlight lens, making direct impacts far less likely. If an optic is ever damaged, it can be replaced for under $20 — versus hundreds of dollars for a complete conventional headlight assembly.
• Modular, Individually Serviceable LED Emitters: Low beam, high beam, and DRL modules are each independently replaceable — often without even removing the headlight assembly from the vehicle. This dramatically reduces long-term ownership costs and downtime.
• High-Strength Die-Cast Aluminum Alloy Housing: Engineered for thermal efficiency, structural rigidity, and long-term corrosion resistance. The aluminum construction also contributes to active thermal management, keeping LED operating temperatures optimal.
• Active & Passive Thermal Management: The aluminum housing dissipates heat to maintain ideal LED performance, and the heated surfaces actively help reduce snow and ice accumulation — a meaningful benefit for Tacoma owners in cold climates or high-altitude off-road environments.
• IP68 Waterproof Assembly: The full headlight assembly is pressure-washer, rain, and snow safe, and engineered to withstand vibration, dirt, debris, and harsh weather conditions — exactly what trail-driven Tacomas encounter.
• IP67 Waterproof DRL: The daytime running light module carries its own IP67 rating and is resistant to salt, UV exposure, acids, and harsh chemicals.
• 9,600 lm Low Beam Output: Delivers a substantial, high-output low beam for improved nighttime visibility over factory halogen or basic LED replacements.
• 6,000K Color Temperature: A crisp, modern white light output that improves road illumination and gives the Tacoma a clean, high-end look.
• Heavy-Duty Reinforced Mounting Brackets: Modular replaceable bracket design improves durability during shipping, installation, and sustained off-road use.
• Automotive-Grade Thermoset Powder-Coat Finish: Superior UV resistance and environmental protection for the housing exterior.
• Paintable Housing Surfaces: Allows OEM+ color-matched styling or a fully custom look to match your build.
• 5-Year Replacement Warranty on All Components: ORACLE backs every element of the Lensless platform with a comprehensive 5-year replacement warranty.

Specifications

• Part Number: 8700-TAC
• Brand: ORACLE Lighting
• Type: Headlight Assembly (Pair)
• Low Beam Output: 9,600 lumens
• Color Temperature: 6,000K
• Optic Material: 1" thick ballistics-grade PMMA
• Housing Material: High-strength die-cast aluminum alloy
• Waterproof Rating: IP68 (assembly); IP67 (DRL module)
• Finish: Automotive-grade thermoset powder coat; paintable housing surfaces
• Warranty: 5-year replacement warranty on all components
• Production: Made to order; please allow 16–24 weeks lead time

Fitment

The ORACLE 8700-TAC Lensless LED Headlights are designed and engineered specifically for the 2016–2023 Toyota Tacoma (3rd Generation). This covers all trims of the Gen 3 Tacoma produced during that model-year range. If you are unsure whether your specific trim or configuration is compatible, contact the ThreePiece.us fitment team before ordering — especially important given the made-to-order lead time on this product.

What's in the Box

The 8700-TAC kit includes the complete headlight assembly with sealed modular LED emitter pods for low beam, high beam, and DRL functions. Individual modules are designed to be independently serviced and replaced. Please confirm full kit contents with ThreePiece.us at the time of ordering.

Why Buy from ThreePiece.us

• Free Shipping on Every Order: No minimum thresholds — your ORACLE Lensless headlights ship free.
• Affirm Financing Available: Split your purchase into manageable payments at checkout through Affirm, making a premium lighting upgrade more accessible.
• Expert Fitment Support: Our team is here to confirm compatibility for your specific Tacoma build before you commit — critical for a made-to-order product with a longer lead time.
• Trusted Source for Premium Lighting: ThreePiece.us carries ORACLE Lighting products and can answer technical questions about installation, wiring, and compatibility with your existing electrical setup.

Frequently Asked Questions

Q: What years and generations of Toyota Tacoma does the 8700-TAC fit?
A: The ORACLE 8700-TAC Lensless LED Headlights are designed exclusively for the 2016–2023 Toyota Tacoma Gen 3. They are not designed for 1st Gen (1995–2004) or 2nd Gen (2005–2015) Tacomas.

Q: Why is the lead time 16–24 weeks?
A: These headlights are made to order, which is part of what allows ORACLE to deliver a precision-engineered, modular platform rather than mass-produced off-the-shelf units. Plan your purchase accordingly and contact us if you have timing questions.

Q: Can I replace individual modules if one is damaged, or do I need to buy a whole new headlight?
A: One of the core advantages of ORACLE's Lensless Architecture is that the low beam, high beam, and DRL modules are individually replaceable — often without removing the full headlight assembly from the vehicle. If an emitter optic is damaged, it can be replaced for under $20, versus hundreds of dollars for a complete traditional headlight replacement.

Q: What warranty does ORACLE provide on the 8700-TAC?
A: ORACLE backs the Lensless LED Headlights with a 5-year replacement warranty on all components, covering the full assembly including the modular emitter pods and housing.
