Your FA20 will thank you for these before it grenades at 80,000 miles. Everyone obsesses over headers and tunes, but the twins have some real weak points that'll leave you with a paperweight if ignored. These aren't the flashy mods that get likes, but they're what separate cars that last from ones that become parts cars.

FA20 FA24 BRZ GR86 reliability modifications oil cooler thermostat engine mounts

Oil Temperature Crisis

Oil temps hit 240°F+ on track days — most BRZ/86 owners cook their motors without knowing it. The FA20 and FA24 run hot by design, and Subaru's oil cooling is barely adequate for street driving, let alone spirited canyon runs or track sessions. Once oil temps exceed 220°F, you're breaking down the oil's protective properties and accelerating wear on bearings, rings, and cylinder walls.

This is where most modified FA20 builds go wrong — owners add power without addressing heat management. If you're planning any modifications beyond intake and exhaust, oil cooling should be your first priority.

Cusco Oil Cooler Kit

Keeps temps under 220°F even on hot track days — $600 prevents $8,000 motor rebuilds. The sandwich plate design fits behind the front bumper with no cutting required, making it the cleanest oil cooler solution for the platform.

Killer B oil pickup tube baffle pan FA20 FA24 installation

The 19-row core with thermostat is perfectly sized for the boxer engine — oil flows normally until 185°F, then routes through the cooler. This prevents overcooling in winter while providing adequate capacity for track abuse. Similar setups like the Chase Bays 19 Row Oil Cooler at $205 offer comparable cooling capacity.

Killer B Pickup Tube

Stock pickup cracks at the weld — oil starvation kills FA20s in hard corners. The factory pickup tube is a known failure point, with cracks appearing around 40,000 miles on cars that see any spirited driving. Once cracked, oil starvation during cornering leads to catastrophic bearing failure.

The baffled oil pan and reinforced pickup costs $400 — insurance against oil pump cavitation. This is a required mod before any track time, especially if you're running forced induction setups that increase cornering speeds. The Killer B system includes proper baffling to keep oil around the pickup under lateral G-forces.

Perrin Engine Mounts

Stock rubber mounts let the motor rock — stress cracks the oil pan over time. The 88 durometer inserts reduce movement by 60% while remaining soft enough for daily driving. At $200 for all three mount positions, they're cheap insurance against oil pan cracking.

The Perrin Manual Trans Mount at $316 complements the engine mounts by reducing drivetrain movement. Solid enough to protect the pan but soft enough for daily driving — unlike solid mounts that turn your cabin into a paint mixer.

Koyo Aluminum Radiator

Stock plastic tanks crack when heat cycled — coolant loss leads to head gasket failure. The all-aluminum construction handles track abuse for $300 versus a $3,000 head gasket job. OEM radiators fail predictably around 60,000 miles on cars that see temperature cycling.

Runs 10°F cooler than stock and keeps the FA24 happy under boost too. If you're building a supercharged GR86, proper cooling becomes even more critical. Alternative options like the CSF radiators starting at $120 offer similar durability improvements.

Prevention Over Repair

These parts cost way less than a rebuild. Oil starvation kills more FA20s than anything else, followed by overheating and stress cracking. Heat management is critical for longevity — OEM mounts turn to jello under stress, and cooling system upgrades prevent the dreaded head issues.

For proper wheel fitment on your reliability-focused build, check our wheel fitment guides and browse Work Wheels for lightweight options that reduce unsprung weight. Don't forget essential accessories like 90 degree valve stems at $3.80 for clearance with aggressive offsets.

Save this before you start modding — your future self will thank you when you're still driving instead of shopping for engines. Visit our vehicle gallery for build inspiration that prioritizes reliability over peak numbers.
